Custom Mixing Reactors 500L–100,000L Stainless Steel Chemical Reaction Vessels Suitable for mixing and dissolving solid-liquid materials in coatings

Name: Custom Mixing Reactors 500L100000L Stainless Steel Chemical Reaction Vessels Suitable for mixing and dissolving solidliquid materials in coatings
Brand: WeSeW
Price: 1 USD

Buy cheap Custom Mixing Reactors 500L–100,000L Stainless Steel Chemical Reaction Vessels Suitable for mixing and dissolving solid-liquid materials in coatings product

Brand Name : WeSeW

Model Number : RG-717

Certification : CE/UL

Place of Origin : china

MOQ : 1 pc

Price : Price Negotiation

Payment Terms : T/T,Western Union

Supply Ability : 10,000 pieces per month

Delivery Time : 10-20 working day

Packaging Details : Wooden Case

Rotation Direction : Clockwise/Counterclockwise

Screw Type : Helicoid or sectional

Strength : High tensile strength

Usage : Conveyor

Inclination Angle : 0-45 degrees

Features : Flexible design, easy to clean

Contact Now

Custom Mixing Reactors 500L–100,000L Stainless Steel Chemical Reaction Vessels Suitable for mixing and dissolving solid-liquid materials in coatings/pigments/dispersions

type

Reaction Kettle

voltage

110V 220V 230V or customized

capacity

500L-10000L

automatic grade

Automatic

power(w)

core components

PLC, Engine, Bearing, Gearbox, Motor, Pressure Vessel, Gear, Pump

Warranty

1 Year

dimension(l*w*h)

Customized

Product name

10000L mixing reaction kettle

Application

paint, coating, inks, pigment

Heating method

Oil Heating

Usage

Mixing Paste Proucts

Color

Customized Color

After-sales Service Provided

Video Technical Support

Mixing Type

Frame Mixer

Stirring speed(rpm)

1450 rmp

Hieght of kettle

2820mm

diamater

2200mm

Application area:

It is applied in coating, agrochemical, printing ink ec chemical industries for mixing, dissloving and dispersing liquid and
solid-liqud materials.

Characteristics

- Few air in and remain during dispersing and excellent mixing and adjusting result. Can quickly dissolving material, smaller
particles in middle or high speed mixing.
- According to different requirements; dispersing kettle can be made in different forms: vacuum, normal pressure,
pressure, cooling, heating etc to fulfill diverse processing techniques.

Type	Capacity L	Power kW	Disc diameter mm	Speed rpm	Diameter mm	Height mm
FDK0.5	500	7.5	250	0-1450	800	1000
FDK1	1000	15	300	0-1450	1000	1250
FDK2	2000	30	350	0-1450	1400	1540
FDK3	3000	37	400	0-1450	1500	1880
FDK4	4000	45	450	0-1450	1600	2180
FDK5	5000	55	480	0-1200	1800	2235
FDK6	6000	75	500	0-1200	1900	2360
FDK8	8000	90	550	0-1000	2000	2720
FDK10	10000	110	600	0-1000	2200	2820

Custom Mixing Reactors 500L–100,000L Stainless Steel Chemical Reaction Vessels Suitable for mixing and dissolving solid-liquid materials in coatings
